Specifications
Repeater
Frequency range (Mhz) UL1920-1980mhz DL2110-2170mhz
Gain (dB) Uplink≥65?Downlink≥70
Bandwidth 60Mhz
Ripple in Band ≤8dB
Output Power (Bm) ≥24dBm±3dBm
Noise figure (dB) 4.5db
Transmission delay (μs) ≤0.5 μs
RF Connector SMA
Coverage area (M) 50-500?
I/O impedence (Ω) 50 Ω
Installation Type Wall Installation
Environment Conditions -10oC-50oC
Power Supply DC 5V
Dimensions (LxWxH) (CM) 13.1*7.3*1.3
Gross Weight (KG) 0.4
General
What’s in the box 1 x User Manual – English, 1* Power Supply, 1 x Mobile Signal Repeater
